P6 Cmd (p6cmd) is a small utility that is designed for the Platform 6 users and support engineers to perform a variety of tasks.

For example:

  • It can be installed on-premise by Platform 6 customers and allows the submission of file(s) to their instances using on-site scripts or ‘file drop’ folder monitoring.
  • It can be installed by Platform 6 Implementation Engineers giving CLI to P6 application lifecycle functionality on any instance.

The latest release of P6 Cmd can be downloaded from here:

Warning

SSO authentication is not available for this application. If you haven’t already, you are required to define a password by editing your profile

P6 Cmd icon

The ‘6’ icon in the notification area of your Task bar (on Windows) or in your Menu bar (on Mac) provides quick access links

  • “Login…” leads to a login page where you shall initially enter your platform6 credentials

  • “Show status” leads to a page displaying four areas:

    1. Status - provides statuses regarding Internet connectivity and login
    2. Login - leads you to the login page (it is greyed when already logged in)
    3. Log Files - allows you to display P6 Sync log and error logs
    4. Quit - well… speaks for itself!

  • “Open P6 Portal…” leads you to the Portal

  • “Logout” removes stored credentials and forces a new user login
  • “Quit P6 Cmd”

Note

The task bar icon is only visible when p6cmd is started in ‘interactive mode’. i.e. Is being used via the browser interface

The browser interface

The browser interface is started automatically after first installation. Once a user has logged in (to access their P6 instances), it is no longer required that P6 Cmd should continue running in this mode. Feel free to quit the browser UI once login is complete.

Note

Authentication credential provision can be scripted allowing use via automation pipelines (see later)

Using the Command Line Interface (CLI)

Once you have logged in, the CLI can be used to interact with your P6 instance(s).

The CLI is designed for use from batch files or shell script, executed by schedulers or run as a service on Windows

To enable CLI access, the p6cmd install folder must be on your PATH.

Warning

On macOS you have to manually add the following you your .bashrc/.profile file:

export PATH="/Applications/P6 Cmd.app/Contents/MacOS:$PATH"

On Windows the user who installs P6 Cmd will automatically have p6cmd added to their PATH. Other users of Windows must extend their on PATH as follows

PATH="C:\Program Files (x86)\Platform6\p6cmd;%PATH%"

Once on the PATH you can invoke the CLI to get help:

$ p6cmd -help

Usage of p6cmd:
  -all-instances
        Apply some operation in all instances (restricted to some actions like list and list-installed)
  -appaction string
        One of [ create | verify | list | list-installed | delete | upload | install | uninstall | upgrade | rollback | package-test ] with optional second argument of file path or app-id
  -configaction string
        Operation related to p6cmd config. One of [ view ]
  -console
        Enable console logging
  -debug
        Enable debug level logging
  -delay int
        Delay in seconds between tasks (default 300)
  -deployed-only
        Hide the test instances used for local development (restricted to the 'appaction list' command)
  -env string
        Infrastructure environment name (dev, staging or prod) (default "prod")
  -headless
        Running without a desktop UI
  -home string
        Location of root folder (default "/Users/simontemple/platform6")
  -ignoretlserrors
        Ignore TLS/SSL related errors
  -instance value
        [Optional and can repeat] Instance names to target
  -instanceaction string
        One of [ list | inventory ]
  -json
        Request output format of JSON (where supported)
  -keygen
        Generate a key pair suitable for App Profile generation
  -limit int
        Limit the number of parallel tasks (default 5)
  -monitorfolders
        Enable folder monitoring for each targeted instance that supports message submission
  -p6noproxy
        Bypass the Platform6 Proxy
  -p6proxyoverride string
        Platform6 Proxy override
  -port string
        Web server localhost listen port, 0 = auto assigned (default "0")
  -sparam value
        [Optional and can repeat] Submission session parameter(s)
  -submit string
        File path or pattern of file(s) to send to each targeted instance that supports message submission
  -timeout int
        Client timeout of requests (default 30)
  -upgrade string
        One of [ full | core ]
  -version
        Print version information

Configuring defaults

The browser UI provides access to a ‘configuration’ screen where a user can configure a number of defaults to save having to re-type them each time on the command line.

Usage: Message Submission

Message Submission is a process of sending one or more files to a Platform 6 instance and triggering a script to process those files. Success or failure results are returned to the message submitter as submission acknowledgement

Message Submission without a user interface (or Portal) is regarded as a more efficient method of regularly transferring files from on-premise folders to a Platform 6 instance for processing and is much easier to automate and integrate into existing on-premise batch processing activities

Platform 6 Message Submission is by its nature flexible and configurable allowing it to fit many project requirements. For example, it has successfully been deployed to a large international supplier community allowing the bulk and regular submission of invoices

Folder usage

During execution, P6 Cmd may automatically create a folder structure on your computer, with a parent folder named “platform6”

On Windows, the “platform6” folder is created on C: in the root (“/”) folder

On OS X, the “platform6” folder is under your user folder (so the path is “/Users/[Your OS X user]/platform6”)

When using p6cmd for file submission, three folders are added beneath a folder named according to each target instance. For example, when targeting an instance with a name of dev:

$ls -al $HOME/platform6/dev
total 16
drwxr-xr-x  6 simontemple  staff   192 23 Feb 11:40 .
drwxr-xr-x  6 simontemple  staff   192 21 Feb 18:24 ..
drwxr-xr-x  5 simontemple  staff   160 23 Feb 11:38 error
drwxr-xr-x  2 simontemple  staff    64 23 Feb 11:40 outbound
drwxr-xr-x  2 simontemple  staff    64 15 Feb 10:17 sent
  • a file that is selected for submission is moved into the outbound folder until the submission is complete
  • files that are accepted by the instance are moved to the sent folder once the submission is complete
  • files that are rejected by the instance are moved to the error folder is the submission fails. A file called error.log is also created in this folder that contains details of why the submission failed

User Permissions

A developer user must have permission messages=* to perform foldermonitor or submit operations

Configuration and Customization for Message Submission

Please refer to Message Submission to configure your instance.

Attributes Set On The /new Endpoint
  • script_name The name of the script to execute when a session is committed or closed
  • [any] All other attributes will be forwarded to the MessageSubmission script as pipeline variables

Examples CLI Invocations

  1. File drop folder monitoring
    $p6cmd -monitorfolders
Logging to: /Users/simontemple/.config/p6cmd/p6cmd.log
    - p6cmd will create a monitor folder for each instance the current user is associated with (and supports message submission) All files copied or dropped into the folder will be submitted to the associated instance. - The contents of the p6cmd.log in this case will look like this:
Version: 1.0.0, Build: 2022-02-23_03:57:34PM (d9ce0e2), Platform: darwin:amd64, Using: go1.17.6 (dev) on 8 CPUs. TimeZone: GMT (0)

INFO: 2022/02/23 15:59:09 restclient.go:189: Port assigned by OS: 56765
INFO: 2022/02/23 15:59:09 restclient.go:226: No http proxy enabled.
INFO: 2022/02/23 15:59:10 restclient.go:531: Created file monitor(s): 1
INFO: 2022/02/23 15:59:10 filestore.go:53: Ensuring file store structure...
INFO: 2022/02/23 15:59:11 filestore.go:97: File store structure ready: /Users/simontemple/platform6/dev
INFO: 2022/02/23 15:59:11 foldermonitor.go:211: Starting folder monitor...

Note

Folder monitoring once started will not end until the process is stopped via a SIGINT signal; via the command shell or process manager

  1. Submit a group of files to a single instance and exit
    $p6cmd -instance dev -submit "/Users/simontemple/Downloads/*.csv"
Logging to: /Users/simontemple/.config/p6cmd/p6cmd.log
$ echo $?
2
  • p6cmd will move the file(s) matching the pattern ~/Downloads/*.csv to the instance folder dev (creating it if does not already exist) and then attempts to submit the files
  • The exit code of 2 indicates that the submission failed (0 = sent without error). Examination of the error.log file in the error folder shows Submission script not found: MessageSubmission
  • MessageSubmission is the name of the script run on the instance as default. For this project the script has been called CSVSubmission so the p6cmd should be:
$p6cmd -instance dev -submit "/Users/simontemple/Downloads/*.csv" -sparam _script_name_=CSVSubmission -sparam foo=bar
Logging to: /Users/simontemple/.config/p6cmd/p6cmd.log
$ echo $?
0

Note

Multiple -sparam arguments are allowed. Each key/value pair are passed as pipeline variables to the submission script. Here, the reserved key of _script_name_ is being used to specify the name of the script to process this submission

Usage: Platform 6 Application (p6app) Lifecycle

Interaction with the Applications Service of a Platform 6 instance is possible using the appaction command line argument with parameter values:

  • list
  • list-installed
  • delete
  • upload
  • install
  • uninstall
  • upgrade
  • rollback
  • package-test
  • create **
  • verify ***

These capabilities were added to allow scripted application test, installation and upgrade.

Note

** The create option is instance independent and is used to create an Application profile (encoded file with .app extension) An Application Profile is required before a developer can start constructing a P6 app

Note

*** The verify option is instance independent and is used to mark a Platform 6 App file (.p6app) as verify (approved for distribution and deployment)

List/List-Installed

The list command takes no arguments and produces a detailed list of all loaded applications on an instance. The list-installed command only lists installed applications

Note

The APP ID is a mandatory parameter to other commands. When using the command you must provide one of those flags : -instance or -all-instances. You can repeat the -instance parameters.

$ p6cmd -appaction list-installed -env dev -instance dev -instance wild-breeze-3764

p6cmd appaction list installed apps

$ p6cmd -appaction list-installed -env dev -all-instances

p6cmd appaction list installed apps on all instances

Delete

The delete command takes an APP ID as parameter to specify the application to delete

$ p6cmd -instance dev -appaction delete 0c0280d10c4246258f23e4fe5d649ba4
 ✔ Using applications service on instance dev (dev)
 ✔ Delete of application: 0c0280d10c4246258f23e4fe5d649ba4 complete.
 ✔ App Action complete

Upload

The upload command takes a path to a p6app file as a parameter. It will upload the app bundle ready for install or upgrade

$ p6cmd -instance dev -appaction upload /tmp/test_test_1_0_2_null.p6app
 ✔ Using applications service on instance dev (dev)
2024/04/10 15:23:54 Failed handling application action: 'upload'
Code: 400
Message: Application upload failed!  An application with the same key, version and status already exists.
$ p6cmd -instance dev -appaction upload /tmp/test_test_1_0_2_null.p6app
 ✔ Using applications service on instance dev (dev)
 ✔ Upload of application file: /tmp/test_test_1_0_2_null.p6app complete.
 ✔ App Action complete

Install/Uninstall/Upgrade/Rollback/Package-Test

All these application bundle commands take an APP ID as parameter

$ p6cmd -instance dev -appaction install 451209c88612411ca56456c381dbcf49
 ✔ Using applications service on instance dev (dev)
 ✔ App Action 'install' started...
    Application installation started for: test-test ...
    Checking target instance version and application version constraints.
    De-serializing application components...
    Installing bundled resources
    Looking for pre-install script to install and execute
    Warning! No scripts bundled with this application.
    Starting to install service items.
    Service: platform6.tables
    Validating and deploying service items to: platform6.tables
    Warning: Overwriting existing service item: test-test.TestTable
    Added service item: test-test.TestTable
    Service: platform6.scripts
    Validating and deploying service items to: platform6.scripts
    Service items installation complete.
    Looking for post-install script to install and execute
    Warning! No scripts bundled with this application.
    Application Installation Complete.
    Waiting for services to start...
    Start of services completed!
 ✔ App Action complete

Note

The messages usually displayed on the user interface progress pane are now displayed on stdout in the terminal

$ p6cmd -instance dev -appaction uninstall 451209c88612411ca56456c381dbcf49
 ✔ Using applications service on instance dev (dev)
 ✔ App Action 'uninstall' started...
    Application uninstall started for: test-test ...
    Starting uninstall of service items.
    Service: platform6.tables
    Service: platform6.scripts
    Service item uninstall complete.
    Application Uninstall Complete.
    Waiting for services to start...
    Start of services completed!
 ✔ App Action complete

Errors and exceptions encountered by the Applications Service are also displayed

$ p6cmd -instance dev -appaction upgrade 6c58365ca1324b56af5707ecf9acf3a1
 ✔ Using applications service on instance dev (dev)
2024/04/10 15:35:10 Failed handling application action: 'upgrade'
Code: 500
Message: Unexpected error starting application action! Cannot use upgrade App without a defined upgrade or post upgrade script! test-test.6c58365ca1324b56af5707ecf9acf3a1
Detail: Cannot use upgrade App without a defined upgrade or post upgrade script! test-test.6c58365ca1324b56af5707ecf9acf3a1

Create

The creation of an Application Profile is a multistep process:

  • Creation or installation of public/private key pair
  • Creation of a JSON properties file
  • Generation of .app file in the local filesystem

The deployment of an Application Profile is also a multistep process:

  • The public key file must be attached to the organisational tree of the * instance at /Trusted Publishers/[app_publisher_id]
  • The App Profile file must be attached to the root node of the instance the app developer is to work on

Note

Deployment is straight forward using the Platform 6 Portal UI and requires orgs=edit permission

Creation Step 1: Keypair creation

Public/private keys are a required part of Application security, ensuring only trusted application publishers can install their apps on Platform 6.

All Platform 6 Applications are signed using the private key when they are packaged and verified using the public key when they are installed.

An application publisher can generate the required key pair using the CLI:

$ p6cmd -keygen
RSA key pair generated successfully!
 ✔ KeyGen Action complete

Execution time : 2.480974006s

Warning

Running this command more than once can overwrite the key files, please ensure you have copies of these files before confirming the overwrite when prompted!

Key files are created in your p6cmd users configuration folder:

  • key-private.pkcs8
  • key-public.pem

Note

You can find your user configuration path using the command p6cmd -configaction view

Warning

Once a key pair has been generated for a “publisher” (i.e. Your organisation/company) all App Profiles created by your organisation should use the same key pair

Creation Step 2: JSON properties file

A JSON properties file is required as a mandatory input parameter to the -appaction create option.

In its most basic form it must contain an app.key which is the globally unique id for the application.

Other optional properties:

  • app.logo: Application logo data uri format: https://en.wikipedia.org/wiki/Data_URI_scheme (Use https://www.base64-image.de/)
  • app.name.n: A list of locale specific names for the application, where n is a number from zero. The value is a comma separated key/value pair with key of the ISO 639-1 language code
  • app.description.n: A list of locale specific descriptions for the application, where n is a number from zero. The value is a comma separated key/value pair with key of the ISO 639-1 language code

Note

A language code of EN will be used as the default when no matching locale code is found

Examples:

{
  "app.key": "ondiflo"
}

{
  "app.key": "ondiflo",
  "app.name.0": "EN,Ondiflo",
  "app.name.1": "FR,Ondiflo",
  "app.description.0": "EN,Ondiflo: Tank Monitor",
  "app.description.1": "FR,Ondiflo: Moniteur de réservoir"
}
Creation Step 3: App Profile Generation

Once the key pair and JSON files have been created/installed, generation of the Application Profile is simple:

$ p6cmd -appaction create profile.json

p6cmd appaction create

The app.publisher.id

This value is defaulted to the p6cmd configuration property application/publisherId and stored in the file psconfig.json

This value should be updated for publishing organisations other than Sidetrade. Configuration properties can be maintained via the WEB UI Settings panel.

If this configuration value is removed/empty and is not specified directly in the JSON file, the app.published.id will be auto generated and globally unique

The app.publisher.id is important and must be noted/retained for the following reasons:

  • As a required part of the Trusted Publishers organisational tree
  • Must be used to regenerate the App Profile (for name or logo changed for example)
  • Has an implicit link with the key pair used to generate it

The app.publisher.id can be specified in the JSON properties file:

{
  "app.key": "ondiflo",
  "app.publisher.id": "apps@sidetrade.io"
}

Warning

It is essential that the key-pair and app.publisher.id are always used together.

$ p6cmd -appaction create profile.json

p6cmd appaction create

Verify

App (Connector App) verification is the process of awarding a .p6app file with a verified status. This signifies that the content has been quality checked by one or more Platform 6 moderators and the App passed all current quality checks.

Warning

This option must only be used by Platform 6 App moderators

The verify action does not perform quality checks, it simply marks the App as verified.

$ p6cmd -appaction verify Amalto_O2C_2_0_3_final.p6app
 ✔ App Action complete

Execution time : 70.790124ms

However, if the App is already verify:

$ p6cmd -appaction verify Amalto_O2C_2_0_3_final.p6app
2025/01/20 14:12:08 Failed handling application action: 'verify' file already verify encoded

Usage: Platform 6 Instance Actions

Interaction with the Authorisation Service of Platform 6 is possible using the instanceaction command line argument:

  • list
  • inventory

The list capability was added to allow scripted operations that require instance id. (technical identifier)

List

The list command takes no arguments and produces a detailed list of all instances the current user has permission to use

$ p6cmd -instanceaction list

p6cmd instanceaction list

The deployed-only flag can be used to filters the instances : instances used for local development will be removed from the results.

$ p6cmd -instanceaction list -env dev -deployed-only

p6cmd instanceaction list deployed instances only

Inventory

The inventory command takes no arguments and display the network/cloud configurations used for the deployment of the instances :

  • instance ID
  • region (EU or NA or )
  • hostname
  • cloud (sidetrade or ovh or digital ocean or )
  • p6 proxy

Note

This action requires the p6cmd user to be connected to the Sidetrade network because of nslookup in the backend : region and cloud values can be retrieved by checking the private IP of the p6core instance.

$ p6cmd -instanceaction inventory -env dev

p6cmd instanceaction inventory

Usage: Platform 6 Upgrade Actions

Auto-Upgrade Initiation via the Applications Service of Platform 6 is possible using the upgrade action with either of the arguments:

  • full
  • core

Note

This action only initiates the upgrade, it does not wait until the upgrade is complete. A successful initiation will result in a P6 job-id being returned.

During the auto-upgrade, there is a risk of increasing the workload on the p6 services, this can be avoided by doing upgrade by groups and add a pause between each group upgrade. To perform upgrade by groups, use the -limit parameter (default value 5). By default a pause of 300 secondes is done before proceeding the next group, this pause can be overridden with the parameter -delay.

core

Will upgrade the Platform 6 docker container to the :latest

This means the most recent release of the container called p6core with the latest tag

If there has been no new release of p6core newer than that running, no action will be performed.

Note

In fact any container named p6* will be upgraded. This will ensure auto-update of and Platform 6 Sidecar type containers also

$ p6cmd -env dev  -limit 5 -delay 60 -instance green-night-1211 -upgrade core
2024-09-25 11:03:49 [go-routine][green-night-1211] Request upgrade to p6core instance ...
2024-09-25 11:03:50 [go-routine][green-night-1211] Job ID : 040867a14c5a4c09a9db550d806988ca
2024-09-25 11:03:50 [go-routine][green-night-1211] Request is completed
Pause for 60 secondes ...
 ✔ Instance Upgrade Action complete

Execution time : 1m1.4858281s

full

Will upgrade all installed applications to the @latest and also perform a core upgrade

This means that for each installed application the P6 Application Repository will be checked for a newer version using the @latest tag

When newer versions exist, the current versions will be uninstalled and following the core upgrade the latest version of each of the Applications is installed

$ p6cmd -env dev  -limit 5 -delay 60 -instance aged-sound-4025 -instance green-night-1211 -upgrade full
2024-09-20 08:34:17 [go-routine][green-night-1211] Request upgrade to p6core instance ...
2024-09-20 08:34:17 [go-routine][aged-sound-4025] Request upgrade to p6core instance ...
2024-09-20 08:34:17 [go-routine][aged-sound-4025] Job ID : 4c11e6f161864f918e56f3d6311acd07
2024-09-20 08:34:17 [go-routine][aged-sound-4025] Request is completed
2024-09-20 08:34:17 [go-routine][green-night-1211] Job ID : 61ea58f3a10e4fa38137eed163ab986a
2024-09-20 08:34:17 [go-routine][green-night-1211] Request is completed
Pause for 60 secondes ...
 ✔ Instance Upgrade Action complete

Execution time : 1m1.579986421s

User Permissions

The p6cmd user must have the permission instance=upgrade to perform upgrade operations and be associated with the instance (or * admin)

$p6cmd -env dev -instance dev -upgrade core
 ✔ Using applications service on instance dev (dev)
2024/07/22 17:02:44 Failed handling instance upgrade action: 'core'
Code: 404
Message: HTTP 404 Not Found

Warning

Upgrade initiation is only supported on Platform instances version 6.10.4 onwards Instances that do not support upgrade initiation will return 404!

JSON Formatted Output

The new argument -json can be added to the command line to request output written to stdout is formatted as JSON

Not all CLI actions support this format selector. Those that do are: - instanceaction - appaction - upgrade

Example:

$ p6cmd -instanceaction list -json
[
    {
        "Enabled": true,
        "Name": "*",
        "DisplayName": "",
        "InstanceType": "CORE",
        "Description": "b2Auth Authentication Server",
        "Picture": "",
        "Properties": {
            "baseContext": "https://login.amalto.com",
            "infoPath": "/apis/v2/info"
        },
        "IsLocal": false,
        "Version": "",
        "P6Proxy": ""
    },
    {
        "Enabled": true,
        "Name": "Airswift_Prod",
        "DisplayName": "",
        "InstanceType": "CORE",
        "Description": "Airswift - Prod",
        "Picture": "",
        "Properties": {
            "baseContext": "https://prod.airswift.sidetrade.io/b2box/rest/resource",
            "infoPath": "/apis/v2.1/info"
        },
        "IsLocal": false,
        "Version": "5.24.21",
        "P6Proxy": ""
    },
    {
        "Enabled": true,
        "Name": "autumn-cloud-5131",
        "DisplayName": "Kal-Tire_v6_Prod",
        "InstanceType": "CORE",
        "Description": "Kal Tire V6 Prod instance",
        "Picture": "",
        "Properties": {
            "baseContext": "https://prod.kaltire-v6.sidetrade.io/p6",
            "emailTemplateOverride": "sidetrade",
            "infoPath": "/apis/v2.1/info"
        },
        "IsLocal": false,
        "Version": "6.10.4",
        "P6Proxy": "p6caddy/1.1.3"
    },
    {
        "Enabled": true,
        "Name": "Bell-Supply_Prod",
        "DisplayName": "",
        "InstanceType": "CORE",
        "Description": "Bell Supply - Prod",
        "Picture": "",
        "Properties": {
            "baseContext": "https://prod.bell.b2box.com/b2box/rest/resource",
            "infoPath": "/apis/v2.1/info"
        },
        "IsLocal": false,
        "Version": "5.24.21",
        "P6Proxy": "nginx/1.23.4"
    },
    {
        "Enabled": true,
        "Name": "blue-truth-1738",
        "DisplayName": "Pro-Mach_Prod",
        "InstanceType": "CORE",
        "Description": "Pro-Mach Prod instance",
        "Picture": "",
        "Properties": {
            "baseContext": "https://prod.promach.sidetrade.io/p6",
            "infoPath": "/apis/v2.1/info"
        },
        "IsLocal": false,
        "Version": "6.10.7",
        "P6Proxy": "p6caddy/1.1.3"
    },
<snip>

Note

This format is much easier to parse and integrate into automated pipelines

Authentication Credential Provision

Three environment variables can be used:

  • P6CMD_TOKEN_TYPE
  • P6CMD_REFRESH_TOKEN
  • USE_P6CMD_CREDENTIAL_FILE

Note

These values override any values stored in credentials files

Warning

Each time you run p6cmd with environment variable, a new bearer token is generated and will not be reused. To prevent this, you can use the environment variable USE_P6CMD_CREDENTIAL_FILE set to 1. p6cmd will automatically switch to the credential file as soon as the file is created in the system.

For example:

export P6CMD_TOKEN_TYPE=Bearer
export P6CMD_REFRESH_TOKEN=d438577fa4fa9ac4d15c2395152e88fA1
export USE_P6CMD_CREDENTIAL_FILE=1

Depending upon the execution environment (dev,staging or prod) the file:

  • [env].p6cmd_credentials.json

is usually used. This file is created after a successful sign-in via the browser.

Note

Once created, the refresh token can be copied from this file for use as an environment variable.

Switching Environments

The files:

  • dev.p6cmd_credentials.json
  • staging.p6cmd_credentials.json
  • prod.p6cmd_credentials.json

can all exist in the p6cmd auth folder and selected using the -env command line argument.

You can inspect the p6cmd credentials with -configaction command.

$ p6cmd -configaction view -env dev
Reading dev credential at C:\Users\ilangovane.ragavanan\AppData\Roaming\p6cmd\dev.p6cmd_credentials.json...
Access token found :
* Issuer : http://amalto.com
* Subject : p6cmd
* Expiration : 2025-02-06 16:01:15 +0000 UTC
* Not valid before : 2025-02-06 15:01:15 +0000 UTC
* Issued at : 2025-02-06 15:01:15 +0000 UTC
* Type of token : JWT
* Realm : b2
* User : ilangovane.ragavanandane@sidetrade.com
 ✔ Config Action complete

$ p6cmd -configaction view -env staging
Reading staging credential at C:\Users\ilangovane.ragavanan\AppData\Roaming\p6cmd\staging.p6cmd_credentials.json...
Access token found :
* Issuer : http://amalto.com
* Subject : p6cmd
* Expiration : 2025-02-06 15:51:12 +0000 UTC
* Not valid before : 2025-02-06 14:51:12 +0000 UTC
* Issued at : 2025-02-06 14:51:12 +0000 UTC
* Type of token : JWT
* Realm : b2
* User : ilangovane.ragavanandane@sidetrade.com
 ✔ Config Action complete
Execution time : 210.0044ms

$ p6cmd -configaction view -env prod
Reading prod credential at C:\Users\ilangovane.ragavanan\AppData\Roaming\p6cmd\prod.p6cmd_credentials.json...
Access token found :
* Issuer : http://amalto.com
* Subject : p6cmd
* Expiration : 2025-02-06 15:49:32 +0000 UTC
* Not valid before : 2025-02-06 14:49:32 +0000 UTC
* Issued at : 2025-02-06 14:49:32 +0000 UTC
* Type of token : JWT
* Realm : b2
* User : ilangovane.ragavanandane@sidetrade.com
 ✔ Config Action complete
Execution time : 627.692ms
